Brick, curve and free-form panels for creative walls.
Each series ships in several standard model variants, so you can match the screen to your space, resolution and budget.
A pixel pitch from 8 keeps text, images and video crisp even at close viewing distance — built for demanding indoor and outdoor content.
Each pixel uses a 1R1G1B configuration for stable, saturated color reproduction across content.
Designed for landmark architecture, lobbies and brand spaces that need visual impact — backed by an experienced LED engineering team in Shenzhen.
Every system is backed by our service commitment — warranty, technical support and spare parts for long-term operation.
Directly from the DS Visual product catalog.
| 点间距（mm） | 8 |
| 像素组成 | 1R1G1B |
| LED扫描方式 | 1/4 scan |
| 屏幕亮度（cd/m²） | ＞1700 |
| 模组平均功率（W） | 10.5 |
| 模组最大功率（W） | 15 |
| 模组输入电压（V） | 5 |
| 屏幕密度（点/㎡） | 15625 |
| LED驱动方式 | 恒流 |
| 显示颜色 | 17M~69G |
| 亮度调节 | 256级亮度可调 |
| 灰度校正 | 256-4096 |
| 图象调节 | 对比度，色调、单模组高亮调节 |
| 刷新频率（帧/S） | 600~1500 |
| 换帧频率（Hz） | ≥60 |
| 视频源（可选） | TV、VCD、DVD |
| 连续使用时间（小时） | ＞72 |
| 使用环境温度（℃） | -35~+60 |
| 使用寿命（小时） | ＞100000 |
